TN Liquid Crystal Attenuator

$195.00

Good utility twisted nematic variable attenuator. Tuned for center of visible light (550nm) and acts as an achromatic variable light valve. Crossed polarizer configuration, 0 Volts yields ON state while 5-10 Volts delivers DARK state.

SKU: VIS-TN-LC Category:

Description

Visible TN Liquid Crystal Attenuator

25.4mm x 26.2mm x 1.8mm

Active area: 22.8mm x 21.8mm

Visible Broadband TN attenuator

features
  • High contrast / Low voltage devices
  • Supplied with crossed polarizers
  • 0-6.4 Volts – 4.4 mSecond rise time, 15 mSecond fall time
  • 0-30 Volts – 150 microSecond rise time, 18 mSecond fall time (due to back-flow)
  • Thin device, 1.75mm thick with polarizers
  • Polarizer transmission axis 0˚ to edge
  • 1000:1 contrast ratio
  • 0 Volts for ON state
  • 5-10 volts DARK state, typical

Additional information

Weight 0.45 kg
Dimensions 32.0 × 28.0 × 4.0 cm
Unit Size

25.4mm x 26.2mm x 1.75mm
